Diaphragm Seals and Isolators
Find the optimal Ashcroft® diaphragm seals and isolation rings for your application by using the filtering options provided.
Ashcroft® diaphragm seals and isolation rings protect valuable instruments from potential damage caused by corrosive media or clogging from sludge or slurries, especially in wastewater processing. Diaphragm seals are offered in a variety of configurations with a wide selection of compatible wetted materials, such as 316 stainless steel, Monel and Tantalum. Isolation rings are available in different diameters for integration into piping systems. They provide a contiguous, flexible inner wall that deflects to equally pressurize the fill fluid into the pressure measuring device.Showing 1-12 of 30 products
![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/100-200-300_Seal_Front-1024x1024.jpg)
200-201 Threaded Diaphragm Seals
The Ashcroft® 200 and 201 threaded diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, these are also applied when media exhibit...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/102-202-302_Seal_Front.jpg)
202-203 Flanged Diaphragm Seals
The Ashcroft® 202 and 203 diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, they are also applied when media can potential...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/80_WaferR_Connection_Group-1.jpg)
80 Wafer Isolation Ring
The Ashcroft® 80 isolation ring is mounted inline with process piping. Used for process protection of measuring instruments, the ring-design eliminates process accumulation, assuring accurate...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/100-200-300_Seal_Front-1024x1024.jpg)
100-101 Threaded Diaphragm Seals
The Ashcroft® 100 and 101 threaded diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, these are also applied when media exhibit...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/102-202-302_Seal_Front.jpg)
102-103 Flanged Diaphragm Seals
The Ashcroft® 102 and 103 flanged diaphragm seals protect pressure measuring instruments. Used when process compatibility is required, they are also applied when media exhibit...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/81_Bolt_Thru_ISO-Ring_6_C1.jpg)
81 Bolt Thru Isolation Ring
The Ashcroft® 81 isolation ring is mounted inline with process piping. Used for process protection of measuring instruments, the ring-design eliminates process accumulation, assuring reliable...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/510-seal.jpg)
510-511 All-Welded Diaphragm Seals
The Ashcroft® 510 and 511 compact, all-welded diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/310_Seal.jpg)
310-315 Mini-Diaphragm Seals
The Ashcroft® 310 and 315 mini-diaphragm seals protect pressure measuring instruments. Used to ensure process compatibility, they are also applied when process media exhibit pulsation...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/82_ISO_Ring_C.jpg)
82 Threaded Isolation Ring
The Ashcroft® 82 isolation ring is threaded in-line with process piping. It is designed for threaded piping systems to protect pressure measuring instruments. The ring-design...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/DF_Seal_D.jpg)
DF Flush Flanged Diaphragm Seal
The Ashcroft® DF flush flanged diaphragm seal uses a diaphragm welded directly to the assembly flange. This eliminates much of the cost associated with bulky...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/740-741-Seal.jpg)
740-741 High-Displacement Diaphragm Seals
The Ashcroft® 740 and 741 high-displacement diaphragm seals are used with low-ranged instruments or high static pressure differential pressure gauges with low differential pressure. Used...![Product](https://www.ashcroft.com/wp-content/uploads/2020/09/330_Diaphragm_Seal.jpg)
