1339A Duplex Pressure Gauge
The Ashcroft® 1339A duplex pressure gauge is used for pressure measurement of two independent points. An easy solution for users seeking to reduce system complexity and cost, this model provides high reliability and performance. An ideal product for satisfying critical installation requirements.
Key Features:
- Non-adjustable red and black pointers
- Two independent systems and movements; bronze Bourdon tubes
Applications:
Industrial Market:
Filters
Pumps and Valves
Rail Braking Systems
Specialized OEM Equipment
Specifications
Certifications & Approvals
Data Sheets & Instruction Manuals
Drawings & Product/Technical Information
Accuracy
±2%-1%-2% of span (ASME B40.100 Grade A)
Size
4 1/2"
Process Connection Size
1/4 NPT
Process Connection Location
Lower, Back
Pressure Ranges
30 to 1,000 psi
Case Style
Solid Front
Weather Protection
Case not sealed, recommended for weather protected environment only
Mounting
flush
Stem, Surface
